Round Lane assignment Lights

What is a Lane Assignment Signal (LAS) ?

A lane assignment signal with a red cross and green arrow is a signaling device used to manage access and traffic on a lane (on a road, in a tunnel, at the entrance to a parking lot, on a toll road, or in a logistics area).

• Red cross: the lane is closed to traffic. Vehicles must not use it.
• Green arrow: the lane is open and can be used.

This light is used to ensure traffic safety by preventing vehicles from entering a closed or dangerous lane, regulating traffic by directing drivers to available lanes, and optimizing traffic flow management.

Technical specifications

• Dimensions: 360x360mm – thickness: 145mm
• Aluminum casing and rear panel
• Translucent polycarbonate front panel
• Opens on one side thanks to stainless steel hinges and latches
• High-intensity LEDs: 105 red LEDs for the CROSS symbol and 78 green LEDs for the ARROW symbol
• Resistance: IP55
• Option: signal status control

A tailor-made product

We manufacture track assignment lights in our workshop to meet your specifications. We can adapt the dimensions, symbols, color of the housing, type of power supply, and even the mounting method. Our team is available to discuss your project!

For example, our track assignment signals are available with 24V or 230V power supplies to suit your infrastructure. The standard mounting system uses two rails on the back of the box, but other systems are available on request.
